Caos
Caos
frattali
I frattali sono il segno del caos, la sua firma
ma la loro struttura é alla base di molte forma naturali anche, perché assai semplice ed economica, e alla Natura questi algoritmi iterativi basati su elementi semplici piacciono assai..
Ma questa stessa semplicità permette anche di realizzarli elegantemente con un programmino di calcolatore, ad esempio in Java..
<import java.awt.Graphics;
public class c14_mandelbrot extends java.applet.Applet {
static final int left = 20;
static final int w = 300;
static final double r = 2;
static final double s = 2*r/w;
static final double recen = 0;
static final double imcen = 0;
static final int kstart = 0;
static final int kend = -99;
static final int kstep = -3;
public void paint(Graphics g)
{
LineTo lt = new LineTo(g);
lt.drawLine((int)(-1/s+left+w/2), left+w/2, (int)(1/s+left+w/2), left+w/2);
lt.drawLine(left+w/2, (int)(-1/s+left+w/2), left+w/2, (int)(1/s+left+w/2));
int x[] = new int[3];
int y[] = new int[3];
for (int k = kstart; k >= kend; k += kstep) {
boolean ok = false;
int i;
for (i = 0; i < 10000; i++) {
if (outside(k, s*i + recen, imcen)) {
ok = true;
break;
}
}
if (!ok) {
break;
}
int vin = 0;
int vout = 1;
int vnew = 2;
x[vin] = i-1;
x[vout] = i;
x[vnew] = i;
y[vin] = 0;
y[vout] = 0;
y[vnew] = 1;
int xin = x[vin];
int yin = y[vin];
int xout = x[vout];
int yout = y[vout];
lt.setPixel(x[vin]+left+w/2, -y[vin]+left+w/2);
do {
int vref;
if (!outside(k, s*x[vnew]+recen, s*y[vnew]+imcen)) {
lt.lineTo(x[vnew]+left+w/2, -y[vnew]+left+w/2);
vref = vin;
vin = vnew;
vnew = vref;
} else {
vref = vout;
vout = vnew;
vnew = vref;
}
x[vnew] = x[vin] + x[vout] - x[vref];
y[vnew] = y[vin] + y[vout] - y[vref];
} while (x[vin] != xin || y[vin] != yin || x[vout] != xout || y[vout] != yout);
}
}
boolean outside(int k, double rec, double imc)
{
double re = rec;
double im = imc;
for (int j = 0; j < 2-k; j++) {
double re2 = re*re;
double im2 = im*im;
if (re2 + im2 > 256) {
return true;
}
im = 2*re*im + imc;
re = re2 - im2 + rec;
}
return false;
}
}
>
che disegna il classico insieme di Mandelbrot
